Specially designed for outdoor uses, ideal for long-distance wireless data transmission over 5km+, tested in the field. 5km+

������

• Built-in 9dBi 2x2 dual-polarized directional MIMO antenna
• Adjustable transmission power from 0 to 25dBm/500mw
• System-level optimizations for more than 5km long range wireless transmission
• TP-LINK Pharos MAXtream TDMA (Time-Division-Multiple-Access) technology improves product performance in throughput, capacity and latency performance, ideal for PTMP applications
• Centralized Management System ��������� Pharos Control
• AP / Client /������AP Router / AP Client Router (WISP) operation modes
• Passive PoE Adapter supports up to 60 meter (200 feet) Power over Ethernet deployment and all"text-align: center;">

  ������"width: 100%; border-style: solid; margin-left: auto; margin-right: auto;" border="1"> HARDWARE FEATURES

  Processor Qualcomm Atheros 560MHz CPU, MIPS 74Kc Memory 64MB DDR2 RAM, 8MB Flash Interface 1 10/100Mbps Shielded Ethernet Port (LAN0,Passive PoE in)
  1 Grounding Terminal
  1 Reset Button Power Supply Passive Power over Ethernet via LAN0 (+4,5pins; -7,8pins)
  Voltage range: 16-27VDC Power Consumption 5 Watts Max
  Note: When deployed using Passive PoE, the power drawn from the power source will be higher by some amount depending on the length of the connecting cable. Dimensions ( W x D x H ) 224 x 79 x 60 mm Antenna Type Built-in 9dBi 2x2 Dual-polarized Directional Antenna
  Beam Width: 65������ (H-Plane) / 40������ (E-Plane)
  Note: For more details, please refer"tr_1051"> Protection 15KV ESD Protection
  6KV Lightning Protection Enclosure Outdoor ASA stabilized plastic material
  IPX5 waterproof Certification
