TP-LINK���������s 2.4GHz 300Mbps 12dBi Outdoor CPE, the CPE220 is dedicated to cost-effective solutions for outdoor wireless networking applications. With its centralised management application, it is flexible and ideal for point-to-point, point-to-multipoint and outdoor Wi-Fi coverage applications. ������Professional performance, coupled with user-friendly design, makes CPE220 an ideal choice for both business and home users.

������

������

• Built-in 12dBi 2x2 dual-polarized directional MIMO antenna
• Adjustable transmission power from 0 to 30dBm/1000mw
• System-level optimizations for more than 13km long-range wireless transmission
• TP-LINK Pharos MAXtream TDMA (Time-Division-Multiple-Access) technology improves product performance in throughput, capacity and latency performance, ideal for PTMP applications
• Centralised Management System ��������� Pharos Control
ter supports up to 60 meters (200 feet) Power over Ethernet deployment and allows the device to be reset remotely

������"width: 100%; border-style: solid; margin-left: auto; margin-right: auto;" border="1"> HARDWARE FEATURES

Processor Qualcomm Atheros 560MHz CPU, MIPS 24Kc Memory 64MB DDR2 RAM, 8MB Flash Interface 1 10/100Mbps Shielded Ethernet Port (LAN0,Passive PoE in)
1 10/100Mbps Shielded Ethernet Port (LAN1)
1 Grounding Terminal
1 Reset Button Power Supply Passive Power over Ethernet via LAN0 (+4,5pins; -7,8pins)
Voltage range: 16-27VDC Power Consumption 10.8 Watts Max
Note: When deployed using Passive PoE, the power drawn from the power source will
be higher by some amount depending on the length of the connecting cable. Dimensions ( W x D x H ) 11������3.1������2.1 inch (27"tr_1056"> Antenna Type Built-in 12dBi 2x2 Dual-polarized Directional Antenna
Beam Width: 60������ (H-Plane) / 30������ (E-Plane)
Note: For more details, please refer"tr_1051"> Protection 15KV ESD Protection
6KV Lightning Protection Enclosure Outdoor ASA stabilized plastic material
IPX5 waterproof Certification

�����ï
