- 1TB Storage Capacity
- M.2 2280 Form Factor
- PCIe Gen4 x4 NVMe Interface
- Up to 6000MB/s Read Speed
- Up to 5000MB/s Write Speed
- 3D NAND Flash Technology
- 640TBW Endurance Rating
- High-Speed SSD Performance
- Reliable Data Storage
- 5-Year Warranty
CHARGING AHEAD WITH SPEED
From the MSI universe comes storage with blazing speeds and incredible performance. Take your system to the next level with SPATIUM.
PRO Performance Realized
Delivering the ultimate PRO performance for PCIe 4.0, the M470 PRO boasts up to 20% faster random read/write speeds, enabling a supremely responsive experience in gameplay and productivity under heavy workloads.
A Need for Speed!
Optimized for the PCIe Gen4 interface, SPATIUM M470 PRO SSD reaches read/write speeds up to 6000/5000 MB/s, allowing for rapid data transfer and shortened game load times.
Fulfill Unlimited Potential
Built-in data security and error-correction capabilities extend the endurance and longevity of the NAND flash storage, empowering you to break records in games or take your talents to the next level.
BUILT TO WIN
With the gamers’ first attitude, SPATIUM SSDs optimized for high-performance bandwidth and throughput enable you to wait less at loading games and play to win with minimal latency.
CREATE. PRODUCE. DONE.
SPATIUM SSDs get more done by opening up images, movies, documents, and heavy-duty applications at lightning speeds, keeping up your nonstop creativity and productivity.
Real-Time SSD Monitoring & System Stability
Monitor SSD health and key metrics in real time through MSI Center. Stay informed with live updates on drive condition, enabling proactive management to ensure stable and reliable system performance.
Optimal M.2 SSD
Designed in the M.2 2280 form factor, SPATIUM SSDs are easy to install into external SSD enclosures, desktops or laptops, bringing speedy performance and power efficiency to any computing system.
SPECIFICATION
Model Name SPATIUM M470 PRO PCIe 4.0 NVMe M.2
Capacity 1TB
Controller PHISON E27T
Flash Memory 3D NAND
Form Factor M.2 2280
Interface PCIe Gen4 x4, NVMe 1.4
Compatibility PCIe Gen4 / Gen3 / Gen2 / Gen1
Dimensions 80.00mm (L) x 22.00mm (W) x 2.15mm (H)
Sequential Read up to (MB/s) 6000
Sequential Write up to (MB/s) 5000
Random Read 4KB up to (IOPS) 950,000
Random Write 4KB up to (IOPS) 950,000
Maximum Operating Power(W) 4.5
Idle Power PS3 (mW) 50
Low Power L1.2 (mW) 5
Operating Temperatures 0°C – 70°C
Storage Temperatures -40°C – 85°C
Terabytes Written (TBW) 640
Mean Time Between Failure (MTBF) Up to 1,500,000 Hours
Limited Warranty 5 Years, or the coverage for the maximum
TBW as stated, whichever comes first.
Advanced Features TRIM (Performance Optimization, OS Support required)
SMART (Self-Monitoring, Analysis and Reporting Technology)
LDPC (Low Density Parity Check) ECC
Algorithm End to End Data Path Protection
APST (Autonomous Power State Transition)
Pyrite (Encryption, Data Security)
