ASUS NUC 14 Pro Mini PCs, U5-125H, DDR5(0/2), M.2(0/2), WL, NO P/CORD, 3YR RTB
Ā
- Powered by IntelĀ® Coreā¢ Ultra 5 processors
- Intel Arcā¢ graphics on specified SKUs
- IntelĀ® AI Boost on specified SKUs (Intelās newest NPU purpose-built to handle longer-running AI workloads at low power.)
- Dual-channel DDR5-5600MHz SODIMMs, 96GB max
- M.2 22x80 key M slot for PCIe x4 Gen 4 NVMe SSD
- M.2 22x42 key M slot for PCIe x4 Gen 4
- Support for SATA 2.5-inch HDD (Tall kit)
- IntelĀ® Wi-Fi 6E AX211, supporting 802.11ax and Bluetooth Ā 5.3 via internal antennas
- Intel i226 2.5 Gb Ethernet
- Extensive connectivity includes Thunderboltā¢ 4, HDMIĀ® 2.1, USB 3.2 Gen 2, and internal USB 2.0 headers
- OS Not Included' Support: Windows 11 64-bit, Ubuntu 24.04 LTS 64-bit, RedHat Enterprise Linux 64-bit
- IntelĀ® Coreā¢ Ultra 5 Processor 125H, cTDP 40W
- IntelĀ® Graphics
- RAM Not Included' Support: 2 x SO-DIMM Slots, Up to DDR5-5600, 48GB*2
- Storage Not Included' Support: 1 x M.2 2280 PCIe Gen4x4, supports 128GB~4TB NVMe SSD 1 x M.2 2242 PCIe Gen4x4, supports 128GB~2TB NVMe SSD 1 x SATA Port for 2.5in SSD/HDD, supports 128GB~4TB SATA drive (Tall SKU only) *Refer to latest QVL list
- 3 Years Onsite (Barebone)
Ā
Smaller, Faster, Better, AI Enabled
The ASUS NUC brand represents a commitment to technological excellence, prioritizing innovative product design, to push the boundaries of performance and user experience.
Developed through a partnership between ASUS and Intel, the ASUS NUC product lines anchor on delivering uncompromised performance in the smallest form factors, backed by industry best quality and reliability, innovative modular designs, extended lifes pan options, smart cooling solutions, and advanced AI capabilities. The versatility of the products shines through an array of configurations catering to diverse user needs, from developers, to power users, to casual home use. Positioned as the preferred choice for a variety of business applications, vertical industries, and everyday users, the ASUS NUC combines exceptional performance with essential features, aiming to shape the next generation of PC experiences.
With a focus on supporting diverse businesses and enhancing PC applications, the ASUS NUC aspires to deliver on the brand promise of delivering the Next Unit of Compute (NUC) and make a lasting impact in the ever-evolving tech landscape.
Ā
-
Performance: Delivers best-in-class performance among comparable mini-PC offerings
-
Manageability: Most comprehensive mini-PC with Intel vProĀ®Ā Enterprise for exceptional security, manageability, and stability
-
AI Enabled: Harnesses the prowess of IntelĀ®Ā Coreā¢ Ultra processorsā three AI engines for high throughput, low power, and fast response
-
Wi-Fi Sensing: Takes advantage of Wi-Fi sensing to deliver instant availability while reducing power consumption
-
Wireless Connectivity: Delivers seamless connectivity for certified BluetoothĀ®Ā dongle-free experiences
-
Customizable: Designed for toolless chassis access making upgrades easier, safer, and faster
Ā
Compact Power Intelligent Preference
ASUS NUC 14 Pro delivers best-in-class performance thanks to the all-new IntelĀ® Coreā¢ Ultra processor family. It is the most comprehensive mini-PC built with Intel vProĀ® Enterprise for exceptional security, manageability, and stability. With certified BluetoothĀ® dongle-free connectivity and three AI engines ā GPU, NPU, and CPU ā for high throughput, low power, and fast response, ASUS NUC 14 Pro delivers robust computing capabilities. It is equipped with Wi-Fi sensing for intelligent energy efficiency, and a ātried and trustedā 4x4-inch chassis designed for toolless access for easier, safer, and faster upgrades.
Ā
| Type |
PC barebone - mini PC |
| Processor |
1 x Intel Core Ultra 5 (Series 1) 125H / 1.2 GHz (up to 4.5 GHz, (14-core) |
| Processor Main Features |
Intel Smart Cache |
| Cache Memory |
18 MB |
| Cache Per Processor |
18 MB |
| RAM |
0 GB (installed) / 96 GB (max) - DDR5 SDRAM |
| Storage Controller |
SATA (SATA 6Gb/s) |
| Hard Drive |
No HDD |
| Optical Storage |
No optical drive |
| Graphics Controller |
Intel Arc Graphics |
| Networking |
Bluetooth 5.3, 802.11a, Wi-Fi 5, 802.11b/g/n, Wi-Fi 6E, 1GbE, 2.5GbE |
| OS Provided |
No operating system |
| Colour |
Black |
| Dimensions (WxDxH) |
14.4 cm x 11.2 cm x 5.4 cm |
| Weight |
570 g |
Ā
ASUS NUC 14 Pro Tall AI-Enabled Mini PC (IntelĀ® Coreā¢ Ultra 5) (Barebone) RNUC14RVHU500000I
