Future-proof your productivity
Maximise your productivity on a Thunderbolt 5 smart dock, built for seamless multitasking using Gen AI tools across up to four 4K 120Hz displays. Featuring extended power range, this smart dock delivers up to 300W of power over a single USB-C cable to meet the demands of the highest performance AI PCs. Modern ports ensure a wide range of peripheral connectivity.
More manageable and secure
Elevate the IT management experience by directly managing your smart docks from the Dell Device Management Console - no PC connection or software required.
More manageable commercial dock
Reduce IT efforts by scheduling updates during off-hours, while ensuring fleetwide firmware compliance and eliminating end user interruptions.
More secure smart dock
Keep users working confidently with enterprise-grade WPA-3 192-bit encryption for secure Wi-Fi communication. Safeguard your sensitive data with tamper-resistant, hardware-based encryption built into your Dell Pro Smart Dock.
Effortless maintenance
Remotely configure, deploy and update Dell Pro Smart Docks over Wi-Fi without the user connecting to a PC.
Unlock out-of-band management on select Intel vProĀ® PCs with IntelĀ® Active Management Technology (IntelĀ® AMT) over Thunderbolt from the connected dock.
Connect your way
Configure your workspace to your liking with an ambidextrous USB-C cable that can be routed left or right.
Designed for sustainability
The Dell Pro Thunderbolt 5 Smart Dock is built with post-consumer recycled materials and packaged with recycled or renewable packaging.
SPECIFICATIONS
| Model |
Dell Pro Thunderbolt 5 Smart Dock - SD25TB5 |
| Power Delivery (Power Provided) |
300W (Dell Systems) 240W (non-Dell Systems) |
| Interfaces |
Thunderbolt 5 |
| Cables |
83 cm |
| Connectivity Technology |
Wired |
| Screen Mode Supported |
4K @ 60Hz 5K @ 60Hz 6K @ 60Hz 8K @ 60Hz 4K @ 120Hz WQHD @ 60Hz QHD @ 60Hz |
| Power Delivery Details |
4 x USB-A 3.2 Gen 2 (4.5W each) 1 x USB-C 3.2 Gen 2 (15W) 1 x USB-C Multi-function DisplayPort (7.5W) 2 x Thunderbolt 5 (15W each) All deliver power with or without PC |
| Number of Displays Supported |
4 |
| Ethernet Technology |
2.5 Gigabit Ethernet |
| Number of USB Type-A Ports |
4 |
| Number of USB Type-C Ports |
2 |
| Number of USB 3 2 Gen 2 Type-A Ports |
4 |
| Network (RJ-45) |
yes |
| Number of DisplayPorts |
2 |
| Number of HDMI Ports |
1 |
| Weight (Approximate) |
632 g |
| Limited Warranty |
3 Year |
Technical Information
| Cable Length |
83 cm |
| Device Supported |
Desktop PC |
| Notebook |
| Connectivity Technology |
Wired |
| Features |
Power Delivery Pass-through |
| LED Power Indicator |
| Maximum Data Transfer Rate |
1.25 GB/s |
| Number of Displays Supported |
4 |
| Supported Resolutions |
2560 x 1440 |
| 3440 x 1440 |
| 7680 x 4320 |
| 6144 x 3456 |
| 5120 x 2160 |
| 3840 x 2160 |
| Screen Mode Supported |
6K @ 60Hz |
| 8K @ 60Hz |
| QHD @ 60Hz |
| WQHD @ 60Hz |
| 4K @ 120Hz |
| 4K @ 60Hz |
| 5K @ 60Hz |
| Management Features |
Port Disablement |
| MAC Address Pass-through |
| Kernel Direct Memory Access (DMA) Protection |
| Dock Power Button Sync |
| Intel AMT over Thunderbolt with select Intel vPro PCs |
| WLAN to LAN Switch |
| Wake-on-LAN |
| PXE Boot |
| Dell Command Update (DCU) |
| Power Delivery |
240W (non-Dell Systems) |
| 300W (Dell Systems) |
| Video Resolution Details |
QHD - 60 Hz (Quad Display) |
| WQHD - 60 Hz (Triple Display) |
| 4K - 120 Hz (Quad Display) |
| 4K - 120 Hz (Triple Display) |
| 6K - 60 Hz (Dual Display) |
| 8K - 60 Hz (Single Display) |
| 4K - 60 Hz (Dual Display) |
| 4K - 60 Hz (Quad Display) |
| 4K - 60 Hz (Triple Display) |
| 5K - 60 Hz (Single Display) |
| Security Slot Type |
Kensington Security Slot |
| Noble Wedge Security Slot |
| Power Delivery Details |
- 4 x USB-A 3.2 Gen 2 (4.5W each)
- 1 x USB-C 3.2 Gen 2 (15W)
- 1 x USB-C Multi-function DisplayPort (7.5W)
- 2 x Thunderbolt 5 (15W each)
- All deliver power with or without PC
|
