- Complies with ATX 12V V3.1 & EPS 12V V2.92
- Efficiency ≧ 90% at typical load
- 80 PLUS ® gold certified
- 105°C Japanese bulk capacitor
- 120mm hydraulic bearing ( HYB ) fan
- Fully modular cabling design
- Complete protections: OVP, OCP, OPP, OTP, SCP, UVP, SIP, NLO
Complies with Intel Power Design Guide ATX 3.1
Built for the demanding power requirements of tomorrow, these PSUs offer maximum total power excursion support as per ATX 3.1 and PCIe Gen 5.1 specifications, ensuring peak performance with future hardware upgrades.
High Efficiency in Gold-certified
Certified by world-class organizations 80 PLUS® gold certifications and efficiency close to 92% at typical load for lower power loss, less heat, and quieter operation.
LLC Resonant-converter Topology with Synchronous Rectifier
Reducing switching losses, boosting efficiency, and keeping the output voltage regulated under load conditions.
+5V & 3.3V DC to DC Circuit Design
Increase the efficiency and stabilize the output voltage to ensure system stability.
105°C Japanese Bulk Capacitor
Equip your PC with the best-in-class capacitors to offer maximize reliability, performance, and lasting power.
120 mm hydraulic bearing (HYB) fan
Quality bearing keeps fan noise to a minimum while providing maximum cooling performance.
Powerhouse Single +12V Rail
This high-amperage +12V rail delivers high load capabilities, it's ideal for intensive workloads of high-performance CPUs and graphics cards.
The Force Comes with You
Individual CPU 4+4 pin cables provide CPU direct output power to ensure stable operation even under the most demanding workloads.
The Force Comes with You
Dual PCIe 6+2Pin cables and a versatile 12V-2x6 cable offer flexible configuration for even the most power-hungry NVIDIA or AMD graphics cards.
Modular Design with All-White Cables
The VITA GM white version features completely white modular cables and cable connectors, creating an ultra-cool, all-white aesthetic. Its fully modular cabling design makes power supply installation easy, allowing users to use only the needed cables, which improves airflow and reduces system clutter.
Compact PSU Size：140 x 150 x 86mm
140mm in length which is relatively shorter than industry standard, it's ideal for compact PC or space-constraint environment without compromising on performance.
Fortress-level Protection
Our comprehensive circuit shields your valuable components from harm.
Technical Specs
Environmental Conditions
| Maximum Operating Temperature |
40°C |
Miscellaneous
| Energy Efficiency Certification |
80 Plus Gold |
Interfaces/Ports
| Number of SATA Power Connectors |
8 |
| PCI Express Connector |
Yes |
| Number of (4+4 pin) CPU Power Connectors |
2 |
| Number of (6+2 pin) PCI Express Power Connectors |
4 |
| Number of 4-pin Molex Power Connectors |
4 |
Physical Characteristics
| Form Factor |
Internal |
| ATX |
| Height |
86 mm |
| Width |
150 mm |
| Depth |
140 mm |
| Product Color |
White |
| Color Family |
White |
Technical Information
| Efficiency |
90% |
| Fan Diameter |
120 mm |
| Features |
On/Off Switch |
| Low Noise |
| Protection Type |
Over Temperature |
| Over Voltage |
| Short Circuit |
| Under Voltage |
| Surge & Inrush Protection |
| No Load |
| Over Current |
| Over Power |
| Fan Bearing Type |
Hydraulic Bearing |
| Number of Fans |
1 |
| Power Factor Correction (PFC) |
Active |
| Modular |
Yes |
| Specification Compliance |
ATX12V v3.1 |
| EPS12V v2.92 |
General Information
| Product Type |
Power Supply |
| Manufacturer Part Number |
VITA-850GM, W |
| Manufacturer Website Address |
http://www.fspgroupusa.com |
| Manufacturer |
FSP Group USA Corp |
| Product Model |
VITA-850GM (White Edition) |
| Product Name |
VITA-850GM (White Edition) 850W Power Supply |
| Product Line |
VITA GM |
| Brand Name |
FSP Group |
Power Description
| Input Voltage |
120 V AC |
| 230 V AC |
| Output Power |
850 W |
| Output Voltage |
5 V SB |
| -12 V DC |
| 12 V DC |
| 3.3 V DC |
| 5 V DC |
| Output Current |
70.83 A |
| 20 A |
| 3 A |
| 300 mA |
| Input Frequency |
50-60Hz |
| Number of +12V Rails |
1 |
| Output Voltage Detail |
-12 V DC @ 0.3 A |
| 5 V SB @ 3 A |
| 5 V DC @ 20 A |
| 3.3 V DC @ 20 A |
| 12 V DC @ 70.83 A |
