• 256GB Capacity

• M.2 2280 Form Factor

• PCIe 3.0 x4 Interface

• NVMe SSD

• Up to 3200MB/s Read Speed

• Up to 1200MB/s Write Speed

• 1.5 Million Hours MTBF

• 3 Year Warranty

Host Memory Buffer (HMB)
The Host Memory Buffer (HMB) feature utilizes the DMA (Direct Memory Access) of PCI Express to allow SSDs to use some of the DRAM on PC system, instead of requiring the SSD to bring its own DRAM.

SSD Tool Box
The newly updated SSD Tool Box is an application that helps users monitor SSD Status, provides general information such as model name, FW version, health condition, drive optimization and also detects sensor temperature. Moreover, users can clear all the data with the Secure Erase function. You can download the SSD Tool Box from the Support.

Specifications

Interface
PCI-Express 3.0 x4, NVMe 1.4

Form Factor
M.2 2280

Total Capacity
256GB

NAND
3D TLC NAND Flash

External DDR Cache
N/A

Sequential Read speed
Up to 3,200 MB/s

Sequential Write speed
Up to 1,200MB/s

Dimension
80 x 22 x 2.3 mm

Mean time between failure (MTBF)
1.5 million hours

Max. Operating Power
Read : 4.2W; Write : 3.0W

Power Consumption (Idle, PS3)
35mW

Power Consumption(PS4, L1.2)
5mW

Temperature (Operating)
0°C to 70°C

Temperature (Storage)
-40°C to 85°C
