• 250GB Capacity

• M.2 2280 Form Factor

• PCIe 4.0 x4 Interface

• NVMe SSD

• Up to 3600MB/s Read Speed

• Up to 3000MB/s Write Speed

• 1.5 Million Hours MTBF

• 3 Year Warranty

Motherboard support PCIe 4.0 x4 SSD becomes mainstream
Many motherboards support the PCIe 4.0 x4 M.2 slot, from Intel Z490 to AMD X570 and beyond. With the widespread adoption of the PCIe 4.0 x4 M.2 slot in motherboards, upgrading your computer for greater efficiency has become easier. The GIGABYTE Gen4 4000E SSD is the first choice when it comes to boosting performance.

Improved performance for users
The performance boost offered by PCIe 4.0 x4 SSDs goes beyond gaming. For power users who are busy with data processing, file transfers and multitasking, the higher bandwidth of PCIe 4.0 significantly improves the overall performance of the PC. Whether you're managing large data sets or handling intensive tasks, PCIe 4.0 provides a smoother and more responsive user experience.

Faster operating system speed
The increased bandwidth of PCIe 4.0 SSDs results in a faster operating system. Expect instant boot times and fast loading of programmes when using Windows OS. This improvement in everyday usability enhances the overall user experience.

Specifications

Interface
•PCI Express 4.0x4, NVMe 1.4
Form Factor
•M.2 2280
Total Capacity
•500GB
External DDR Cache
•N/A
Sequential Read speed
•Up to 3600 MB/s
Sequential Write speed
•Up to 3000 MB/s
Dimension
•22 x 2.3 x 80 mm
Mean time between failure (MTBF)
•1.5 million hours
Max. Operating Power
•Read: 4300mW
•Write:4400mW
Power Consumption (Idle, PS3)
•40mW
Power Consumption(PS4, L1.2)
•5mW
Temperature (Operating)
•0°C to 70°C
Temperature (Storage)
•-40°C to 85°C

Warranty
1. Limited 3 years or 300TBW.
2. Limited warranty based on 3 years or 300TBW, whichever comes first. (*TBW is evaluated by JEDEC workload standard. )
*TBW (Terabyte Written): Terabytes Written is the total amount of data that can be written into a SSD before it is likely to fail.
3. When the usage of an NVME SSD as indicated by the ""Percentage Used"" (SMART ID: 05) in SMART page of ""GIGABYTE SSD toolbox"" reaches 100 means out of warranty. (A new unused product will show the number of 0)

Note
• Test system configuration: configuration may vary by models, we will choose the latest platform for verification.
• Performance may vary based on SSD's firmware version and system hardware & configuration. Sequential performance measurements based on CrystalDiskMark and IOmeter 1.1.0.
• Speeds based on internal testing. Actual performance may vary.
• 1GB = 1 billion bytes. Actual useable capacity may vary.
