- Thunderbolt 4 docking station
- Supports up to Quad 4K display output
- Up to 96W Power Delivery charging
- Built-in SD memory card reader
- Multiple high-speed USB ports
- Gigabit Ethernet for stable connectivity
- Premium midnight blue desktop design
- Ideal for high-performance workstations
Up to Quad 4K Video via HDMI®, DP, and Thunderbolt™ for MacBook
Provides flexible video connections without the need for cumbersome adapters. Choose between 2 x Thunderbolt™ 4 downstream ports and 1 x DP port for plug-and-play video. Add 2 x HDMI®/DP options with DisplayLink® technology. Supports up to quad 4K @ 60Hz for MacBook M1/M2/ M3 with Pro and Max chipsets (and M3 base chipset with laptop lid closed). Also supports up to triple 4K @ 60Hz for base M1/M2 chipsets.
Designed for MacBook
Delivers the power of Thunderboltâ„¢ 4, reflects the midnight blue aesthetic of the latest MacBook, and is optimized for devices with M1, M2, and M3 chipsets running macOS (11 or later).
Thunderboltâ„¢ 4 Hybrid Technology
Combines Thunderbolt™ with DisplayLink® technology to provide next-level productivity experiences. Transfers up to 40Gbps of data, video, and audio. Provides daisy chain support for SSDs, monitors, and other Thunderbolt™ devices. Blocks peripheral devices from unauthorized access to system memory using Intel VT-d DMA protection.
Up to 100W Charging (96W certified)
Power your MacBook while also charging your connected accessories, including iPhones, AirPods, and Apple watches. Includes KonstantChargeâ„¢, enabling connected devices to charge even when your MacBook is undocked.
Productive 16-in-1 Design
With 16 connection options, provides all the ports you need to get the job done today and well into the future. Includes 1 x Thunderbolt™ host port and 2 x Thunderbolt™ 4 downstream ports capable of data, video, and audio, 1 x USB-C® 3.2 Gen2 10Gbps, 1 x USB-A 3.2 Gen2 10Gbps, 2 x USB-A 3.2 Gen1 5Gbps, 2 x HDMI®/DP, 1 x DP, 1 x 3.5mm combo audio jack, 1 x SD Card reader, 1 x Micro SD Card reader, and 1 x 2.5Gbps Ethernet.
Recycled Materials
The SD5900T is composed of 100% post-consumer recycled (PCR) aluminum* and it is delivered in Forest Stewardship Council (FSC®) certified packaging. *The outer casing of the docking station is made of aluminum. The PCBA and any related inner components are not made of aluminum.
Zero-Footprint Mounting Option and Security Cable Lock Slots
Maximize desktop space by mounting your docking station out of the way. Mounting bracket sold separately (K34050WW). Protect your investment with a Kensington cable lock (K65020WW or K65021WW), sold separately.
3-Year Limited Warranty
Enjoy peace of mind knowing you are covered by Kensington with a professional warranty.
Network & Communication
| Ethernet Technology |
2.5 Gigabit Ethernet |
Software
| Operating System Supported |
Mac OS X 11.0 Big Sur |
| Windows |
Physical Characteristics
| Form Factor |
Desktop |
| Product Color |
Midnight Blue |
| Color Family |
Blue |
Miscellaneous
| Compatibility |
Compatible with Apple MacBook models with M1, M2, and M3 chipsets
|
| Post-consumer-waste% |
100% |
| Brand Compatibility |
Apple |
| Kensington Security Slot |
Yes |
Technical Information
| Device Supported |
Monitor |
| Notebook |
| Connectivity Technology |
Wired |
| Features |
Security Lock |
| Cable Lock Slot |
| Card Reader |
| Plug and Play |
| Charging Capability |
Yes |
| Memory Card Supported |
microSD |
| SD |
| Memory Card Reader |
Yes |
| Maximum Data Transfer Rate |
5 GB/s |
| Number of Displays Supported |
4 |
| Supported Resolutions |
3840 x 2160 |
| Screen Mode Supported |
4K |
| 4K @ 60Hz |
| Security Slot Type |
Kensington Security Slot |
General Information
| Product Type |
Docking Station |
| Manufacturer Part Number |
K35232AP |
| Manufacturer Website Address |
http://www.acco.com.au |
| Manufacturer |
Kensington Computer Products Group |
| Product Model |
SD5900T |
| Product Name |
SD5900T Docking Station |
| Brand Name |
Kensington |
Interfaces/Ports
| Host Interface |
Thunderbolt 4 |
| HDMI |
Yes |
| Number of HDMI Ports |
2 |
| Network (RJ-45) |
Yes |
| DisplayPort |
Yes |
| Total Number of USB Ports |
4 |
| Thunderbolt |
Yes |
| Number of DisplayPorts |
3 |
| Headphone/Microphone Combo Port |
Yes |
| Number of RJ-45 Ports |
1 |
| USB Type-C |
Yes |
| USB Type-C Detail |
1 x USB-C® 3.2 Gen2 10Gbps |
| Number of USB Type-C Ports |
1 |
| Number of USB Type-A Ports |
3 |
| Thunderbolt Ports Quantity |
2 |
| USB Power Delivery |
100W |
| Number of USB 3.2 Gen 1 Type-A Ports |
2 |
| Number of USB 3.2 Gen 2 Type-A Ports |
1 |
| Number of Thunderbolt 4 Ports |
2 |
| USB Type-A |
Yes |
