- 5x 10GbE Ports
- 100Gbps Switching Capacity
- Unmanaged Switch
- Auto-Negotiation
- Plug-and-Play
- Silent Operation
- Fanless Design
- Metal Casing
- Desktop Switch
- TL-SX105 Model
- High-Speed Network Expansion
- TP-Link 10G Switch
Unlock the Highest Performance of 10G/Multi-Gig Bandwidth and Devices
As the flagship 10G product, TL-SX105 is a 5-port 10G desktop switch, providing up to 100 Gbps of switching capacity. Auto-negotiation 5-speed (100Mbps/1G/2.5G/5G/10G) connections sense the link speeds and intelligently adjust for compatibility and optimal performance for all your devices, including 10G NAS, 10G server, workstation, gaming computer, 2.5G/5G/10G WiFi 6 AP, 8K video, desktop, and more.
Built for Smooth LAN Parties
Never host a laggy LAN party again. Experience the unparalleled speed and lower latency, and prioritize gaming traffic with QoS. Let’s begin the unprecedented smooth game!
Silent Operation with Industry-Leading Fanless Design
The revolutionary fanless design ensures unprecedented silent operation, ideal for any home or business. Durable metal casing, desktop/wall-mounting design and professional heat dissipation design are well-suited for different environments.
Just Plug and Play for Internet Access
A plug-and-play design allows for easy deployment without the need for a technician. Auto MDI/MDIX eliminates the need for crossover cables.
|
|
| Standards and Protocols |
IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.1p, 802.3an, 802.3bz |
| Interface |
5× 100Mbps/1Gbps/2.5Gbps/5Gbps/10Gbps Ports, Auto-Negotiation, Auto-MDI/MDIX |
| Fan Quantity |
Fanless |
| External Power Supply |
External Power Adapter (Output: 12 VDC / 2.0 A) |
| LED |
• System Power: 1
• Link/Act Indicators: 5, 1 indicator per port built into each RJ-45 port
|
| Dimensions ( W x D x H ) |
8.9×5.2×1.4 in (226×131×35 mm) |
| Max. Power Consumption |
21.4 W |
|
PERFORMANCE
|
| Switching Capacity |
100 Gbps |
| Packet Forwarding Rate |
74.4 Mpps |
| MAC Address Table |
32 K |
| Packet Buffer Memory |
2 Mb |
| Jumbo Frame |
10 KB |
|
SOFTWARE FEATURES
|
| Advanced Features |
• 802.3X Flow Control
• 802.1p/DSCP QoS |
| Transmission Method |
Store and Forward |
|
OTHERS
|
| Certification |
CE, FCC ,RoHS |
| Package Content |
• 5-Port 10G Multi-Gigabit Desktop/Rackmount Switch TL-SX105
• Power Cord
• Installation Guide
• Rubber Feet |
| Environment |
• Operating Temperature: 0–40 °C (32–104 °F)
• Storage Temperature: -40–70 °C (-40–158 °F)
• Operating Humidity: 10–90% RH non-condensing
• Storage Humidity: 5–90% RH non-condensing |
